Descripción
| Manufacturer / Supplier | Gcabling | Model Number | 41208-029-1 |
|---|---|---|---|
| Material | SPCC Steel | Size | 42U |
| Width | 600mm | Depth | 600mm |
| Height (without castor) | 2000mm | Height (with castor) | 2072mm |
| Static Loading | 1000KG | Accessory | 4 PCS 19″ rails, 40 SETS M6 screw & nuts |
| Front Door | Tempered glass door | Rear Door | Steel door |
| Color | Black | Surface Finish | Degreasing, Pickling, Phosphating, Powder Coated |
| Cabinet Standard | ANSI/EIA RS-310-D IEC60297-2 DIN41494 | Packaging | Disassembled |
Can be in Bulk Package, Strong and Sturdy
Made of high-quality cold-rolled steel sheet
The surface layer has high electrostatic spray strength
Sturdy structure with maximum load 1000 kgs
Structure rugged maximum load 1000 kgs
The side doors can be made with two doors if the depth of cabinet is 800mm
Frequently Asked Questions
How much weight can the cabinet support?
The static loading capacity : 1000KGS
Do you provide installation instructions or videos for the cabinet?
Yes. Each cabinet is supplied with a detailed installation manual. In addition, we can provide an installation video upon request to assist with wall mounting, equipment installation, and cable management.
Which industry standards does this cabinet comply with?
The cabinet is designed and manufactured in compliance with the following international standards:
- ANSI/EIA RS-310-D
- IEC 60297-2
- DIN 41494 Part 1
- DIN 41494 Part 7
These standards ensure full compatibility with all standard 19-inch rack-mounted equipment.
What are the application scenarios of wall-mounted cabinets?
Wall-mounted cabinets are widely used in the following scenarios:
- Data Centers: Ideal for hosting servers, core switches, and high-density IT equipment.
- Telecom & ISP Facilities: Suitable for OLTs, routers, and fiber distribution systems.
- Security & Surveillance Rooms: Houses NVRs, switches, and monitoring systems.
- Structured Cabling Projects: Perfect for patch panels, fiber boxes, PDUs, and entire cabling systems.
What certifications does your cabinet have?
Gcabling network cabinets are certified and tested according to RoHS requirements. The main certifications include:
- Certificate Name: Certificate – Gcabling Network Cabinet (CEROHS-BV) 230317
- Scope: Network cabinet with fan unit, shelf, and related accessories
- Compliance: Directive 2011/65/EU (RoHS) and its amendment (EU) 2015/863 on the restriction of hazardous substances
- Issuing Body: Bureau Veritas Testing Technical Service (Zhejiang) Co., Ltd.
- Test Report: Test Report – Gcabling Network Cabinet Series (CEROHS-BV) 230317, covering detailed testing results corresponding to the certificate
Does the cabinet come with standard accessories?
It includes adjustable feet, heavy-duty castors for floor-standing cabinet,
Meanwhile M6 screw kits for both wall and floor cabinet
(40 sets for cabinets 33U and above ;
20 sets for cabinets from 15U to 33U,
10 set for the cabinet from 4U to 15U).
PDU, Cable manager , shelf, Fan unit can be optional on requested .
What protection level does the cabinet offer?
The cabinet has an IP20 protection rating, suitable for indoor data center and network room environments.
